Tube Ice Evaporator

The tube ice evaporator is one of the key component of a tube ice machine. It is responsible for freezing water into cylinder tube ice with a hollow center. Tube ice evaporators are commonly used in various industries and the size will be different due to ice produced quantity.

Here’s are a few points about OMT tube ice evaporators:

 OMT tube size for the evaporator:

Inside the evaporator, it consists of stainless steel tubes, the inner diameter of the stainless steel is the size of the tube ice.

There are several tube ice sizes: 18mm, 22mm, 29mm, 35mm, 38mm, we can also customized tube size according to customer’s needs. the length of the tube ice can be  30mm to 50mm, but it’s uneven length.

The whole unit of the tube ice evaporator is consists by below parts： the stainless steel water tank which has the water flower inside, the evaporator body, the ice cutter with reducer set, the water dispenser plug etc.

Vary production capacity available for OMT Tube ice evaporator:  no matter you are a new beginner or you are a big ice plant for expend the ice capacity, our tube ice evaporator has capacity from 500kg per day, to 50,000kg per day, the big range should cover your ice needs.

 Blow will show you how the tube ice evaporator work:

 Water flowing: The tube ice evaporator consists of vertical tubes made of materials such as stainless steel or other corrosion-resistant materials. Water is circulated through these tubes, where it is frozen into cylinder type tube ice.

 Refrigerant System:  actually, The evaporator is surrounded by  refrigerant to absorb the heat from the flow water, to make it freeze into ice.

 Ice Harvesting: Once the ice tubes are fully formed, the evaporator warms up slightly by hot gas, to release the tube ice . The tubes are then harvested and be cut to the desired length.
